501-6174
512MB DIMM CR1/LC1
3.3V ECC / 7ns SDRAM
Option 7062

Notes

1. The minimum requirement is four DIMMs of equal size in any group.
2. DIMMs can be installed in any group order.
3. Each group addresses 4GB of memory.
4. The DIMMs in Group 0 do not need to be the same size as those in Group 1.
5. The 501-6173/6174/6175 are 13mm taller than other listed DIMMs.
6. Option 7052A changed from 501-5031 to 501-6109 in August 2003.
   The last shipment date of Options 7052A and X7052A was in April 2004.
7. DIMM 501-7385 was added to F501-5030 in February 2006.
8. DIMM 501-7386 was added to F501-6109 in February 2006.
9. DIMM 501-7385 was removed from F501-5030 in April 2006.
10. DIMM 501-7386 was removed from F501-6109 in April 2006.
11. DIMM 501-7385 was added to Option 7051 in February 2006.
12. DIMM 501-7386 was added to Option 7056 in February 2006.
13. Memory slots (Jxxxx) map to same-numbered DIMMs (Uxxxx):



    Slot	DIMM
    J0407	U0407
    J0406	U0406
    J0305	U0305
    J0304	U0304
    J0203	U0203
    J0202	U0202
    J0101	U0101
    J0100	U0100
